Shielded-Twisted-Pair Cable Model for Chafe Fault Detection Via Time-Domain Reflectometry (Paperback) (ISBN-13: 9781289167912)

This report details the development, verification, and validation of an innovative physics-based model of electrical signal propagation through shielded-twisted-pair cable, which is commonly found on aircraft and offers an ideal proving ground for detection of small holes in a shield well before catastrophic damage occurs. The accuracy of this model is verified through numerical electromagnetic simulations using a commercially available software tool. The model is shown to be representative of more realistic (analytically intractable) cable configurations as well. A probabilistic framework is developed for validating the model accuracy with reflectometry data obtained from real aircraft-grade cables chafed in the laboratory.

Author: Stefan R. Schuet
ISBN-10: 1289167915
ISBN-13: 9781289167912
Publisher: Bibliogov
Language: English
Published: 07/15/2013
Pages: 74
Format: Paperback
Weight: 0.33lbs
Size: 9.69h x 7.44w x 0.15d
