Fpga controlled three phase inverter based bldc motor drive (Paperback) (ISBN-13: 9783659663260)

This book presents a brief overview of the Brush less D.C Machine (BLDCM) covering its construction, classifcation, control, usage etc.Presented further are two possible modeling strategies of this machine and their drawbacks. An attractive method by solving loop equations for instantaneous current is also discussed. This is followed by the simulation of a BLDC motor in the abc/dq frame by using MATLAB/SIMULINK. Some simulation results are presented. Also included are the results of some tests conducted on the machine. Due to the unavailability of the stator neutral, the tests to determine d and q-axis inductances have failed. The analytical reasons are presented. A new method for controlling the drive by a efficient digital controller called Field Programmable gate Array(FPGA) has been discussed. Three phase 1200 voltage source inverter has been simulated successfully using FPGA. The control hardware comprising of FPGA, driver circuit of three phase inverter & inverter module has been run successfully. Results of that test have been presented.

Author: Banerjee Atanu
ISBN-10: 3659663263
ISBN-13: 9783659663260
Publisher: LAP Lambert Academic Publishing
Language: English
Published: 02/11/2015
Pages: 152
Format: Paperback
Weight: 0.51lbs
Size: 9.00h x 6.00w x 0.35d
